Identifikasi Spesies Mangrove dengan Menggunakan Sistem Pesawat Udara Kecil Tanpa Awak di Kawasan Ekosistem Mangrove Sedari, Kabupaten Karawang, Jawa Barat
Mangrove species identification by using a small unmanned aircraft system in Sedari mangrove ecosystem, Karawang regency, West Java
Abstract
Remote sensing is one of the effective methods of monitoring mangrove ecosystems. One of the challenges in implementing this method is image resolution. Access to large-resolution imagery as a basic material for spatial analysis is not cheap. Unmanned small aircraft systems (SPUKTA) or drones are able to answer these challenges. Orthophotos obtained from the acquisition of drones are capable of producing large-resolution imagery. This method is then implemented in conservation areas, to facilitate the process of identifying mangrove species in the area. The drone was flown at an altitude of 150 m with a pavement value of 85% for 4 flying missions. The result of processing 1614 aerial photos into orthophotos produced images with a GSD resolution of 4.75 cm/pix. These images are then analyzed with on-screen digitization techniques and visual interpretation. From the total area of the study area of 46.48 ha obtained the digitization results of Rhizophora sp. with a total area of 24.68 ha, Avicennia sp. 7.64 ha, dead mangroves 0.19 ha, and non-vegetation 13.97 ha.
References
Alfira, R .(2014). Identifikasi Potensi dan Strategi Pengembangan Ekowisata Mangrove Pada Kawasan Suaka Margasatwa Mampie di Kecamatan Wonomulyo Kabupaten Polewali Mandar [Undergraduate’s Thesis, Hasanuddin University]. https://core.ac.uk/download/pdf/25497082.pdf
Bayyan, M. M. (2019). Penggunaan Unmanned Aerial Vehicle (UAV) untuk Pemetaan Mangrove di Kawasan Mangrove Bagek Kembar, Sekotong, Lombok, Nusa Tenggara Barat [Undergraduate’s Thesis, Brawijaya University]. Brawijaya Knowledge Garden Repository. http://repository.ub.ac.id/id/eprint/169629/
Casella, E., Rovere, A., Pedroncini, A., Stark, C. P., Ferrari, M., & Firpo, M. (2016). Drones as tools for monitoring beach topography changes in the Ligurian Sea (NW Mediterranean). Geo-Mar Lett, 36, 151–163. https://doi.org/10.1007/s00367-016-0435-9
Escobar-Sánchez, G., Haseler, M., Oppelt, N., & Schernewski, G. (2021). Efficiency of aerial drones for macrolitter monitoring on Baltic Sea beaches. Frontiers in Environmental Science. https://doi.org/10.3389/fenvs.2020.560237
Floreano, D., & Wood, R. J. (2015). Science, technology and the future of small autonomous drones, Nature, 521(7553), 460–466. https://doi.org/10.1038/nature14542
Giordano, F., Mattei, G., Parente, C., Peluso, F., & Santamaria, R. (2015). MicroVEGA (micro vessel for geodetics application): A marine drone for the acquisition of bathymetric data for GIS applications.. ISPRS - International Archives of the Photogrammetry, Remote Sensing and Spatial Information Sciences, XL55, 123–130. https://core.ac.uk/download/pdf/193622358.pdf
Jayson-Quashigah, P. N., Addo, K. A., Amisigo, B., & Wiafe, G. (2019). Assessment of short-term beach sediment change in the Volta Delta coast in Ghana using data from Unmanned Aerial Vehicles (Drone). Ocean & Coastal Management, 182(1),104952. https://doi.org/10.1016/j.ocecoaman.2019.104952
Jun, K., Jun, B. H., Lee, H., Kim, S., & Tak, W. (2018). The study of utilization and precision based on the comparison and analysis of drone-based coastal hazard data and its application in the ocean environment. Journal of Coastal Research 85, 811-815. https://doi.org/10.2112/SI85-163.1
Kepel, T. L., Suryono, D. D., Ati, R. N. A., Salim, H. L., & Hutahaean, A. A. (2017). Nilai Penting Dan Estimasi Ekonomi Simpanan Karbon Vegetasi Mangrove Di Kecamatan Kema, Sulawesi Utara. Jurnal Kelautan Nasional, 12(1), 61–70. http://dx.doi.org/10.15578/jkn.v12i1.6170
Panjaitan, A., Sudarsono, B., & Bashit, N. (2019). Analisi Kesesuaian Penggunaan Lahan Terhadap Rencana Tata Ruang Wilayah (RTRW) di Kabupaten Cianjur Menggunakan Sistem Informasi Geografis. Jurnal Geodesi UNDIP, 8(1), 248–257.
Pérez‐Alberti, A., & Trenhaile, A. S. (2015). An initial evaluation of drone‐based monitoring of boulder beaches in Galicia, north‐western Spain. Earth Surface Processes and Landforms, 40(1), 105–111. https://doi.org/10.1002/esp.3654
Pongdatu, D. E., Salahudin, K. G., Nur, C. M., & Anggoro, P. D. (2021). Identification Of Building Density Using Uav Mapping Method In Central Kalimantan Regional Settlement Infrastructure. Journal of Marine-Earth Science and Technology, 2(2), 40–53. https://doi.org/10.12962/j27745449.v2i2.215
Prodanov, B., Kotsev, I., Lambev, T., Dimitrov, L., Bekova, R., & Dechev, D. (2019). Drone-based geomorphological and landscape mapping of Bolata Cove, Bulgarian coast. In P. Georgiev & C. G. Soares (Eds.), Sustainable Development and Innovations in Marine Technologies (p. 5). CRC Press. https://doi.org/10.1201/9780367810085
Purwati, R. D., Anggraeni, T. D. A., Sudarmo, H. (2013). Keragaman Karakter Morfologi Plasma Nutfah Wijen (Sesamum indicum L.). Buletin Tanaman Tembakau, Serat & Minyak Industri 7(2), 69–78.
Rudi, F. S., & Harini, R. (2021). The externalities value of mangrove forest conversion into fishponds in the coastal area of wulan delta in demak regency. IOP Conference Series: Earth and Environmental Science, 683, 01202. https://doi.org/10.1088/1755-1315/683/1/012021
Ruwaimana, M. (2016). Like a drone come true: Comparison of Satellite and Drone Imagery for Mangrove Mapping in Seitu Wetland, Malaysia. Brussels.
Ruwaimana, M., Atmaja, N., & Yuda, I. P. (2017). Resolusi Spasial Optimum pada Citra Drone untuk Klasifikasi Spesies Mangrove dengan Metode Maximum Likelihood. Biota, 2(2), 68–76.
Ruwaimana, M., Satyanarayana, B., Otero, V., M Muslim, A., Syafiq A, M., Ibrahim, S., Raymaekers, D., Koedam, N., & Dahdouh-Guebas, F. (2018). The advantages of using drones over space-borne imagery in the mapping of mangrove forests. PloS one, 13(7), e0200288. https://doi.org/10.1371/journal.pone.0200288
Salim, H. L., Ati, R. N. A., & Kepel, T. L. (2018). Pemetaan Dinamika Hutan Mangrove menggunakan Drone dan Penginderaan Jauh di P. Rambut, Kepulauan Seribu. Jurnal Kelautan Nasional, 13(2), 89–97. http://dx.doi.org/10.15578/jkn.v13i2.6639
Sriyana, I., Niyomukiza, J. B., Sangkawati, S., & Parahyangsari, S. K. (2020). Determination of the original coastline on Semarang city and Demak district using remote sensing approach. E3S Web Conferences, 202, 04001. https://doi.org/10.1051/e3sconf/202020204001
Tufaila, M., Karim, J., & Alam, S. (2012). Pemetaan Penginderaan Jauh dan Sistem Informasi Geografis untuk Pemetaan Bentuklahan di Das Moramo. Jurnal Agroteknos, 2(1), 9–20.
Ventura, D., Bruno, M., Lasinio, G. J., Belluscio, A., & Ardizzone, G. (2016). A low-cost drone based application for identifying and mapping of coastal fish nursery grounds. Estuarine, Coastal and Shelf Science, 171, 85–98. https://doi.org/10.1016/j.ecss.2016.01.030
